Size: 115/54/16 (Click for explanation)
Among others suitable for:
Honda XL250R stator alternator 1982 1983
Honda XL350R stator alternator 1984 1985
Honda XR350R stator alternator 1983 1984 1985
Honda XL400R stator alternator 1982
Honda XL500R stator alternator 1982
Honda XR500R stator alternator 1983 1984
Honda XL600L stator alternator 1983 1984 1985
Honda XL600R stator alternator 1983 1984 1985 1986 1987
Honda XR600R stator alternator 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000
Honda PD03 stator alternator
OEM numbers:
31120-KB7-004 / 31120-KB7-415 / 31120-KL3-004 / 31120-KG0-004 / 31120-KF0-004 /
31120-KF0-771 / 31120-KN5-416 / 31120-KN5-004 / 31120-KN5-406 / 31120-MC4-004 /
31120-KB7-405 / 31120-MG3-015 / 31120-MG2-005 / 31120-MG2-015 / 31120-MK2-005 /
31120-MK2-651 / 31120-MK2-741 / 31120-MN1-640 / 31120-MN1-650 / 31120-MN1-671 /
31120-MN1-681 / 31120-MN1-711 / 31120-MN1-831 / 31120-MN1-832
We manufacture a wide range of generators to fit new and older motorcycles.
Most of our generators are now supplied ready to fit with pre-installed grommet and connectors for quick and easy fitting.
We only fit OEM connectors.
All products supplied are new, eliminating the need for customers to send in the old ones.
1 Year warranty.
| Original color | CARG4101 . |
| B/R | B/R |
| P | P |
| W/Y | W/Y |
| Y/W | Y |
| Ground (frame) . | G |
Warning! This stator may not be suitable for use with stator covers similar to the image below. The stator wiring may get damaged while mounting the stator.
